Engine | 48-volt DC |
Horsepower | 3.3 hp (2.4 kW) rated; Peak 13 hp (9.6 kW) |
Batteries | (6) 8-volt Flooded Lead Acid |
Charger | E.R.I.C. (650 watt high frequency) |
Max. Speed | 5-17 mph (8-27 kph) |
Fuel Capacity | N/A |
|
|
Steering | Self-adjusting Rack and Pinion |
Front Suspension | Independent leaf spring w/dual hydraulic shocks |
Turning Radius | 108.7 in. (276.2 cm) |
Ground Clearance | 5.6 in. (14.2 cm) |
|
|
Brakes | Self-adjusting, rear wheel mechanical drum |
Park Brake | Foot Operated, Multi-lock |
|
|
Body and Finish | ArmorFlexTM with automotive paint/clearcoat |
Tires | 20 x 10 - 10, 6-ply |
| |
Overall Length | 110.1 in. (279.6 cm) |
Overall Height | 47.1 in. (119.6 cm) |
Wheelbase | 65.5 in. (166.3 cm) |
Curb Weight | 1,105 lbs (501.2 kg) |
Bed (LxWxH) | 36.2 x 47.5 x 10.5 in (91.9 x 120.6 x 26.6 cm) |
Bed Load Capacity | 300 lbs (136 kg) |
Towing Capacity | 800 lbs (362.9 kg) |
Total Payload Capacity | 800 lbs (362.9 kg) |
| |
Powertrain and Frame | 3-year/3,000-hour limited warranty |
Remaining vehicle | 2-year limited warranty |
Battery | 4-year limited warranty |
